Falcon W581CP6D Grade 2 Storeroom Cylindrical Lock, Key in Lever Cylinder, Hana Knob, Standard Rose, Satin Chrome W581CP6D HAN 626
Sale price
$49.54
Regular price $103.00
Free shipping on orders over $295.
- Veteran-owned
- Since 1989
- Member of NARPM
Ordering for a whole property? Get a project quote.
Details
Overview
The Falcon W581CP6D is a Grade 2 cylindrical storeroom lock from the W Series. It mounts in a standard cylindrical door prep and is used on storerooms, utility rooms and other doors that need controlled access. The key operates through a cylinder in the lever or knob, and the rose is standard. Falcon is an Allegion brand. Part W581CP6D HAN 626 is the Key in Lever Cylinder, Hana Knob, Standard Rose version in Satin Chrome.
- Key in Lever Cylinder
- Hana Knob
- Standard Rose
- Finish 626 Satin Chrome
- Grade 2
- Fire rated: Yes
- Part number W581CP6D HAN 626
| PRODUCT SPECS | |
|---|---|
| Manufacturer | Falcon |
| ADA | No |
| Commercial/Residential | Light Duty Commercial |
| Fire Rated | Yes |
| Grade | Grade 2 |
| Product Warranty | 10 Year Warranty |
| PRODUCT FINISH | |
|---|---|
| Finish | 626 |
| Finish Description | Satin Chrome |
| TECHNICAL SPECS | |
|---|---|
| SKU | W581CP6D HAN 626 |
| Series | W Series |
| Main Category | Locksets |
| Sub-Category 1 | Cylindrical |
| Backset (#) | 2.75 |
| Base Material | Brass Bronze |
| Bore Hole Diameter (#) | 2.125 |
| Can Be Keyed | Yes |
| Cylinder Type | Conventional |
| Door Handing | Non-handed |
| Door Range (Thickness) | 1-3/8" - 1-3/4" |
| Electronic | No |
| Function | Storeroom |
| Keyway | C Keyway |
| Latch Throw (#) | 0.5 |
| Latch Bore Diameter (#) | 1 |
| Latch Description | Dead Latch |
| Latch Dimensions | 1-1/8" x 2-1/4" |
| Latch Number | 30-197 |
| Maximum Door Thickness (#) | 1.75 |
| Minimum Door Thickness (#) | 1.375 |
| Strike Description | ASA Strike |
| Strike Dimensions | 1-1/4" x 4-7/8" |
| PRODUCT DIMENSIONS | |
|---|---|
| Projection (#) | 2.563 |
| PACKAGE DIMENSIONS | |
|---|---|
| Box Depth (#) | 7.25 |
| Box Height (#) | 6.75 |
| Box Weight (#) | 2.3 |
| Box Width (#) | 3.75 |
