$194.45
SKU MD-31DOW
Skip to product information
MD-31DOW
Sale price
$194.45
Regular price $277.00
Free shipping on orders over $295.
- Veteran-owned
- Since 1989
- Member of NARPM
Ordering for a whole property? Get a project quote.
Details
Overview
| PRODUCT SPECS | |
|---|---|
| SKU | MD-31DOW |
| Manufacturer | SDC |
| Series | MD31D Series |
| Application | For use in "Request to Exit" applications |
| Certification | UL 294 Listed |
| Commercial/Residential | Commercial |
| Country of Origin | United States |
| Grade | Grade 1 |
| Product Warranty | 5 Year Warranty |
| Type | Passive Infrared |
| UOM | 1 |
| UPC | 840067662670 |
| PRODUCT FINISH | |
|---|---|
| Finish | White |
| Finish Description | White |
| TECHNICAL SPECS | |
|---|---|
| Contact Rating | 1A @ 30 VDC Contact Rating |
| Contacts | (2) SPDT, Dry Contacts |
| Current | 26mA @ 12 or 24 VDC/AC Current |
| Door Handing | Non-handed |
| Door Range (Thickness) | - |
| Function | Infrared Request to Exit |
| Interior/Exterior | Interior/Exterior |
| Mount | 7' to 15' Mounting Height |
| Operating Temperature | 14 to 122 Degrees F |
| Range | 6' to 12' Coverage |
| Selling Quantity | 1 |
| User Codes | 0 |
| Voltage | 12-24 VAC/DC Voltage |
| PRODUCT DIMENSIONS | |
|---|---|
| Dimensions | 7" x 2" x 2" |
| PACKAGE DIMENSIONS | |
|---|---|
| Box Depth (#) | 4 |
| Box Height (#) | 5.25 |
| Box Weight (#) | 1.2 |
| Box Width (#) | 8.175 |
