Rixson H345 Center Hung Long Throw Top Pivot, Satin Chromium H345 626
Sale price
$788.16
Regular price $1,318.00
Free shipping on orders over $295.
- Veteran-owned
- Since 1989
- Member of NARPM
Ordering for a whole property? Get a project quote.
Details
Overview
This is a concealed center hung top pivot with a long throw. It sets into the top of a door and works with a bottom pivot to carry the door and let it swing. We list it for pivot-hung doors that need a hinge hidden from view. Part H345 626 comes in Satin Chromium.
- Finish 626 Satin Chromium
- ANSI A156.4, UL Listed
- Part number H345 626
| PRODUCT SPECS | |
|---|---|
| SKU | H345 626 |
| Parent Manufacturer | Assa Abloy |
| Manufacturer | Rixson |
| Series | Not Applicable |
| Application | For use with Rixson Center Hung (Earthquake Tolerant) Pivot Applications |
| Certification | ANSI A156.4, UL Listed |
| Commercial/Residential | Commercial |
| Grade | Not Graded |
| Product Warranty | 2 Year Warranty |
| Type | Concealed Center Hung Top Pivot Hinge |
| UOM | 1 |
| PRODUCT FINISH | |
|---|---|
| Finish | 626 |
| Finish Description | Satin Chrome |
| TECHNICAL SPECS | |
|---|---|
| Base Material | Brass Bronze |
| Door Handing | Non-handed |
| Door Range (Thickness) | - |
| Electronic | No |
| Includes | Not Applicable |
| Maximum Door Weight (lbs) | Not Applicable |
| Screw Pack | Wood/Machine Screws |
| Selling Quantity | 1 |
| Sub-Type | Top |
| PRODUCT DIMENSIONS |
|---|
| PACKAGE DIMENSIONS | |
|---|---|
| Box Depth (#) | 8.375 |
| Box Height (#) | 3.5 |
| Box Weight (#) | 2 |
| Box Width (#) | 2.5 |
