Arrow E64 Grade 2 Classroom Deadlock, Conventional Cylinder, Field Reversible, Satin Chrome E64 26D
Sale price
$60.06
Regular price $105.00
Free shipping on orders over $295.
- Veteran-owned
- Since 1989
- Member of NARPM
Ordering for a whole property? Get a project quote.
Details
Overview
This is a Grade 2 classroom deadlock for interior doors where the lock is operated from the room side or by key from outside. It is field reversible, so one lock fits doors of either hand. We list it for schools and other facilities that need a classroom function deadbolt. Part E64 26D is the Conventional Cylinder, Field Reversible version in Satin Chrome.
- Conventional Cylinder
- Field Reversible
- Finish 26D Satin Chrome
- Grade 2
- ANSI A156.5, Grade 2, UL Listed
- Part number E64 26D
| PRODUCT SPECS | |
|---|---|
| SKU | E64 26D |
| Parent Manufacturer | Assa Abloy |
| Manufacturer | Arrow |
| Series | E Series |
| Certification | ANSI A156.5, Grade 2, UL Listed |
| Commercial/Residential | Commercial |
| Country of Origin | Mexico |
| Grade | Grade 2 |
| Product Warranty | 1 Year Warranty |
| UOM | 1 |
| UPC | 840067637814 |
| PRODUCT FINISH | |
|---|---|
| Finish | US26D |
| Finish Description | Satin Chrome |
| TECHNICAL SPECS | |
|---|---|
| Backset (in) | 2-3/8" |
| Base Material | Brass Bronze |
| Bore Hole Diameter (in) | 2-1/8" |
| Can Be Keyed | Yes |
| Cylinder Type | Conventional |
| Deadbolt Throw (in) | 1" |
| Door Handing | Non-handed |
| Door Range (Thickness) | 1-3/8" - 1-3/4" |
| Electronic | No |
| Function | Classroom |
| Includes Cylinder(s)? | Yes |
| Interior/Exterior | Interior/Exterior |
| Keyway | A Keyway |
| Latch Bore Diameter (in) | 1" |
| Latch Description | Square Corner |
| Latch Dimensions | 1-1/8" x 2-1/4" |
| Latch Number | 141 |
| Maximum Door Thickness (in) | 1-3/4" |
| Minimum Door Thickness (in) | 1-3/8" |
| Number of Keys | 2 |
| Number of Pins | 6 |
| Selling Quantity | 1 |
| Strike Description | Rectangle Strike |
| Strike Dimensions | 1-1/8" x 2-3/4" |
| Strike Number | 346 |
| PRODUCT DIMENSIONS |
|---|
| PACKAGE DIMENSIONS | |
|---|---|
| Box Depth (#) | 4.5 |
| Box Height (#) | 3 |
| Box Weight (#) | 1.5 |
| Box Width (#) | 4 |
